Shell Heat Transfer Oil S2_209Liter

High Performance Heat Transfer Fluid

Shell Heat Transfer Oil S2 is based on carefully selected, highly refined mineral oils chosen for their ability to provide
superior performance in indirect closed fluid heat transfer systems.

System efficiency
Low viscosity enables excellent fluidity and heat transfer over a
wide temperature range. Shell Heat Transfer Oil S2 also has
a low vapour pressure so resists cracking. This minimises the
formation of volatile decomposition products; these would
require recovery via expansion chamber and condensate
collector.
·
Wear protection
Shell Heat Transfer Oil S2 is non-corrosive and has high
solvency – this reduces deposit formation by holding oxidation
products in solution and keeping internal surfaces of heat
exchangers clean.

Shell Heat Transfer Oil S2 can be used in high temperature
continuous heat transfer equipment with the following
application limits:
·
Max. film temperature : 320ºC· Max. bulk temperature : 300ºC

Specifications, Approvals & Recommendations
Classified as ISO 6743-12 Family Q

· Meets DIN 51522 requirements· Meets GB 23971-2009, L-QB 300 requirements

· For a full listing of equipment approvals and rec
